D0096, Fasco Ventilation Motor, 1/15-1/30Hp, 1 Ph, 60 Hz, 115 V, 1050 RPM, 2 Speed, 42 Frame, OAO

D0096, Fasco Ventilation Motor, 1/15-1/30Hp, 1 Ph, 60 Hz, 115 V, 1050 RPM, 2 Speed, 42 Frame, OAO Replace : SS096 Omnidrive, 71870420R, Fasco D143, D143,71870420R Feature Specification Application Furnace Blower, Air Handler, Fan Coil Motor Frame Size 42 Frame (5" Diameter) Motor Type Permanent Split Capacitor (PSC) Capacitor Required 5 Mfd - 370V (Not Supplied) Thermal Protection Automatic Enclosure Open Air Over Insulation Class B Ambient Temperature 40°C Bearing Type Ball Bearings (Drive & Opp. Drive End) Voltage 115V Output Power 1/15 - 1/30 HP (0.05 kW) Speed 1050 RPM Service Factor 1 Frequency 60 Hz Current 1.4 A Duty Continuous Air Over Number of Speeds 2 Rotation Clockwise Shaft End Mounting Extended Studs (Opposite Shaft End) Shaft Type 3/8" Diameter with Flat Shaft Extension 3.5 in Frame Material Rolled Steel Frame Length 3.56 in Certifications UL Recognized, CSA Certified, CE: No About FascoRegal-Rexnord has been manufacturing and distributing draft inducers, blowers, and fractional horsepower motors for the commercial HVAC industry under the Fasco brand for over 100 years.Innovation is the name of their game. Using the latest in technology and their expertise in the electric motor industry, Fasco develops customized furnace motors to meet and exceed the demands of their customers. With over 100 engineers and technicians, they are devoted to motor design and testing that evolves along with the demands of industry.These problem solvers focus on efficiency in their designing and manufacturing processes to provide innovative and cost-effective products to their customers.

• Voltage: 115V 60 Hz
• Output Power: 1/15 - 1/30 HP (0.05 kW)
• Speed: 1050 RPM
• Rotation: Clockwise Shaft End Mounting: Extended Studs (Opposite Shaft End) Shaft Type: 3/8" Diameter with Flat
• Replace : SS096 Omnidrive, 71870420R, Fasco D143, D143A,
